ISL9440B, ISL9440C

t SSx = 0.8V ? -------------------- ?

? 1.55 μ A ?

Pin Descriptions

BOOT3, BOOT2, BOOT1 (Pin 20, 26, 31)

These pins are bootstrap pins to provide bias for high side

driver. The bootstrap diodes are integrated to help reduce

total cost and reduce layout complexity.

UGATE3, UGATE2, UGATE1 (Pins 21, 27, 30)

These pins provide the gate drive for the upper MOSFETs.

PHASE3, PHASE2, PHASE1 (Pins 19, 25, 32)

These pins are connected to the junction of the upper

MOSFETs source, output filter inductor, and lower MOSFETs

drain.

LGATE3, LGATE2, LGATE1 (Pins 22, 28, 29)

These pins provide the gate drive for the lower MOSFETs.

PGND (Pin 23)

This pin provides the power ground connection for the lower

gate drivers for all PWM1, PWM2 and PWM3. This pin

should be connected to the sources of the lower MOSFETs

and the (-) terminals of the external input capacitors.

FB3, FB2, FB1, LDOFB (Pin 16, 13, 6, 10)

These pins are connected to the feedback resistor divider

and provide the voltage feedback signals for the respective

controller. They set the output voltage of the converter. In

addition, the PGOOD circuit uses these inputs to monitor the

output voltage status.

ISEN3, ISEN2, ISEN1 (Pin 18, 24, 1)

These pins are used to monitor the voltage drop across the

lower MOSFET for current loop feedback and overcurrent

protection.

PGOOD (Pin 2)

This is an open drain logic output used to indicate the status

of the output voltages AND input voltage. This pin is pulled

low when any of the three PWM outputs is not within 10% of

the respective nominal voltage, or if the linear controller

output is less than 75% of its nominal value, or VIN pin

voltage drops below 5.55V.

The PGOOD pin also indicates the VIN pin status for early

warning function. If the voltage on VIN pin drops below

5.55V, this pin will be pulled low.

SGND (Pin 11)

This is the small-signal ground, common to all 4 controllers,

and is suggested to be routed separately from the high

current ground (PGND). In case of one whole solid ground

and no noisy current going through around chip, SGND and

PGND can be tied to the same ground copper plane. All

voltage levels are measured with respect to this pin. A small

ceramic capacitor should be connected right next to this pin

for noise decoupling.

9

VIN (Pin 4)

Use this pin to power the device with an external supply

voltage with a range of 5.6V to 24V. For 5V ±10% operation,

connect this pin to VCC_5V.

For ISL9440B and ISL9440C, the voltage on this pin is

monitored for early warning function. If the voltage on this

pin drop below 5.55V, the PGOOD will be pulled low. RST

will be low after PGOOD toggles to low for 5.5μs (TYP).

Refer to Figure 1 for detailed time sequence.

VCC_5V (Pin 3)

This pin is the output of the internal 5V linear regulator. This

output supplies the bias for the IC, the low-side gate drivers,

and the external boot circuitry for the high-side gate drivers.

The IC may be powered directly from a single 5V (±10%)

supply at this pin. When used as a 5V supply input, this pin

must be externally connected to V IN . The VCC_5V pin must

be always decoupled to power ground with a minimum of

4.7μF ceramic capacitor, placed very close to the pin.

EN/SS3, EN/SS2, EN/SS1 (Pin 17, 14, 5)

These pins provide an enable/disable function and soft

starting for their respective PWM outputs. The output is

disabled when the pin is pulled to GND. When a capacitor is

connected from one of these pins to the ground, a regulated

1.55μA soft-start current charges this capacitor during soft

starting. When the voltage on the EN/SSx pin reaches 1.3V,

the corresponding PWM output is active. From 1.3V to 2.1V,

the reference voltage of the corresponding PWM channel is

clamped to the voltage at EN/SSx minus 1.3V. The

capacitance of the soft-start capacitors sets the soft-starting

time and enable delay time. Setting the soft-starting time too

short might create undesirable overshoot at the output

during start-up. It is recommended that the soft-starting time

be greater than 1.0ms. Please do not float this pin.

The typical soft-start time is set according to Equation 1:

C SSx

(EQ. 1)

G4 (Pin 9)

This pin is the open drain output of the linear regulator

controller.

OCSET3, OCSET2, OCSET1 (Pin 15, 12, 7)

A resistor from this pin to ground sets the overcurrent

threshold for the respective PWM.

RST (Pin 8)

Reset pulse output. This pin outputs a logic LOW signal after

PGOOD toggles to low for 5.5μs (TYP). It can be used to

reset system.

Refer to Figure 1 for detailed time sequence with early

warning function.

FN6799.3
